Types of Jib Cranes
The trolley hoist on a horizontal load-bearing boom are key features on Jib cranes. The boom is secured to a vertical mast that measures up to 20 feet long. Jib cranes could transport loads between any areas within the boom's arc of rotation. Light duty models are utilized in warehouses and factories for loads weighing as much as 5 tons. The web site BestJibCranes.com features the major kinds of jib cranes as being either free-standing, wall-mounted or mast mounted.
Free Standing
Free-standing jib cranes could stand alone not needing support from the building structure. The horizontal boom in this specific situation is connected to a pivoting vertical column that is anchored solidly to the building floor. This type of jib crane requires a foundation made of either steel or concrete and can rotate a full 360 degrees.
Mast-Type
The mast-type jib cranes feature a vertical column which is supported by pivot points at the top and the bottom that are attached to the floor of the building and the overhead steel structure. These jib-cranes offer 360 degrees of rotation with the benefit of not requiring the massive foundation required for free-standing units.
Wall Mounted
Wall mounted jib cranes are connected to the wall of the building instead of supporting a regular vertical column. These cranes provide a horizontal boom. These machinery provide up to 200 degrees of rotation and are ideal in places where the full 360 degree rotation is not needed.
There are two model varieties, depending on how the boom is supported. One of the types uses a tie rod which is attached from above the wall to the boom. The other kind supports the boom from below by using a cantilever brace that is attached to the wall also.
