Genie telescopic S-booms have a horizontal reach of between 9.65 meters and 24.38 meters and working heights of 14.20 meters to 40.15 meters. Compared with various other aerial work platforms, telescoping booms have a much greater range of horizontal reach. Genie telescopic booms are designed with consideration to being able to access tight places during construction and industrial applications. They are also known for their ability to maneuver through a job site rapidly and with great drive speed and traction. The platform turns 160�° hydraulically and could stay level through the whole range. Front-entry platforms come with 227 kilogram to 272 kilogram capacity for tools and operators and are available from 1.83 meters to 2.44 meters. Continuous, 360�° rotating turntables offer easy, quick positioning for operators.
The Z-135/70 unit comes equipped with a Jib-Extend, which is a telescoping jib. It extends from 3.66 meters to 6.1 meters. This specific model could also reach 110�° vertically to give the user the ability to reach jobs that were previously unreachable by standard jibs. A secondary reverse-articulating boom on the Z-80/60 unit gives the user 8.83 meters of up and over reach. This specific feature enables over and up reaching tasks to be done with zero front arm swing.
The Fast Mast System built by Genie allows for time to be saved when both secondary and primary booms platform needs to either be lowered or lifted without needing to lower the secondary boom. The Fast Mast system enables both booms to be fully raised simultaneously. Both of these features of the Genie Fast Mast system lessens the time needed for users to ascend and descend, increasing both efficiency and productivity.
