Terex Manlift Specifications
Terex is a Westport, Connecticut company which specializes in producing in manufacturing construction machinery. Equipment like manlifts, boom lifts and aerial lifts. These types of machines are designed to facilitate access to difficult to reach places, large equipment, roofs and buildings, among other things. A manlift, as defined by the U.S. Occupational Safety and Health Administration or also known as OSHA refers to a power-driven endless belt. This belt moves only in one direction and contains steps or handholds or paltforms that are connected to the unit to be able to transport workers from each floor.
TB85
Terex's TB85 man lift provides a max working height at 91 feet. The max height of the platform reaches 85 feet, while the model's maximum width is 8.5 feet. The TB85 has dimensions measuring 9 feet, 1-inch high and 9 inches wide by 36 feet. This particular model provides a reach of 70 feet. The TB85 has a boom angle above horizontal reaching 75 degrees and below horizontal measures at -14 degrees.
Terex TB100
The Terex TB100 man lift's maximum height is 106 feet and the maximum height of the platform is 100 feet. The TB100 when stowed away, is roughly 8.5 feet wide by 9 feet high by 8 feet. The maximum width of the unit is 8 feet, 1 1/2 inches. The boom angle below horizontal is -14 degrees and above horizontal is 75 degrees. The horizontal reach measures at 67 feet, 4 inches.
TB110
The Terex TB110 man lift reaches a max height of 100 feet, whilst the max working height measures at 116 feet. The model is 9 feet, 4 inches high x 8 feet wide when stowed away. The TB110 offers a horizontal reach of 67 feet and a maximum width of 8 feet. This model has a boom angle of 75 degrees above horizontal plus ten degrees articulating. It measures -105 degrees articulating and below horizontal it is -14 degrees.
